PRODUCT CENTER

<

Automatic sequin punch press machine series

Product application"

  • Main technology and feature:
  • General specification
  • Work Video
  • Additional device

Main technology and feature:

1、Electric control system: industrial grade arm architecture A8 processor; full touch  true color industrial display screen; storage capacity of 100 million needles;

2、Color-changing structure: high precision and fast color-changing with closed-loop motor and ball screw;

3、Head structure: balanced head structure to reduce vibration.Positioning  pin available to ensure installion accuracy;

4、Punch components:

(1) Modular design, any combinations of sizes can be switched;

(2) Independent motorto feed sequins, specifications accordance anddistance control;

(3) Double guide and high concentricity, also long service life of the punch press heads;

(4) High precision of the punch head assembly.

Embroidery frame:

(1) High-precision lightweight independent suspension frames, stable and consistent height of the 5、needle drop;

(2) Pneumatic connection for easy unloading;

(3) Electrostatic film design: high viscosity and precision.Easy to switch between stickers;

(4) Infrared cross-positioning marker, humanized design for easy operation and error reduction.


General specification

ModelColorHeadHead intervalFrame  AreaWork area Machine SizeStandard Size
SINSIM-ASP12011210510*450460*4101210*10200.8*3+1.0*2+1.2*2+1.5*2+2.0*2+3.0*1
SINSIM-ASP80484600530*590490*5503450*14170.8*2+1.0*2+1.2*2+1.5*1+2.0*1
SINSIM-ASP810810550600*750600*6507950*20570.8*2+1.0*2+1.2*2+1.5*1+2.0*1
